Mlabwrap is a high-level python to Matlab® bridge that lets Matlab look like a normal python library.

Thanks for your terrific work on this very-useful Python tool!

—George A. Blaha, Senior Systems Engineer, Raytheon Integrated Defense Systems

**2011-08-26** Dani Valevski has asked me to link to the low-level pure python
interface for Matlab® he has written. It can be used by mlabwrap in lieu of
mlabraw.cpp, removing the need to compile against Matlab® one frequent source
of installation difficulites. I haven't been able to test it but it sounds
very useful.

The files are in: [windows version] http://code.google.com/p/danapeerlab/source/browse/trunk/freecell/depends/common/python/matlabcom.py [osx/linus verison] http://code.google.com/p/danapeerlab/source/browse/trunk/freecell/depends/common/python/matlabpipe.py [small hack to make mlabwrap work with these files] http://code.google.com/p/danapeerlab/source/browse/trunk/freecell/depends/common/python/mlabraw.py

**2009-10-26** 1.1 fixes an incorrect declaration in `mlabraw.cpp`
that caused compilation problems for some users and incorporates a
`setup.py` fix for windows suggested by Alan Brooks. More significantly
there is a new spiffy logo!

**2009-09-14** 1.1-pre finally brings N-D array support, thanks to Vivek
Rathod who joined the project! Also fixed a missing import for saveVarsInMat
(thanks to Nicolas Pinto).

Since a few people have run into problems that appear to relate to compiling Matlab® C-extensions in general and aren't mlabwrap-specific, I should probably stress that in case of any problems that look C-related, verifying whether engdemo.c works is a great litmus test (see Troubleshooting ).

**2009-03-23** 1.0.1 is finally out. This is a minor release that fixes some
annoying but mostly minor bugs in mlabwrap (it also slightly improves the
indexing support for proxy-objects, but the exact semantics are still subject
to change.)

- installation is now easier, in particularly
`LD_LIBRARY_PATH`no longer needs to be set and some quoting issues with the matlab call during installation have been addressed. - sparse Matlab® matrices are now handled correctly
(
`mlab.sparse([0,0,0,0])`will now return a proxy for a sparse double matrix, rather than incorrectly treat at as plain double array and return junk or crash). - replaced the (optional) use of the outdated netcdf package for the unit-tests with homegrown matlab helper class.
- several bugs squashed (length of mlabraw.eval'ed strings is checked, better error-messages etc.) and some small documentation improvements and quite a few code clean-ups.

Many thanks to Iain Murray at Toronto and Nicolas Pinto at MIT for letting themselves be roped into helping me test my stupidly broken release candidates.

mlabwrap is under MIT license, see LICENSE.txt. mlabraw is under a BSD-style license, see the mlabraw.cpp.

<http://sourceforge.net/projects/mlabwrap/>

(P.S. the activity stats are bogus -- look at the release dates).

If you're lucky (linux, Matlab binary in `PATH`):

python setup.py install

(As usual, if you want to install just in your homedir add `--prefix=$HOME`;
and make sure your `PYTHONPATH` is set accordingly.)

If things do go awry, see Troubleshooting.

Although I myself use only linux, mlabwrap should work with python>=2.4 (even downto python 2.2, with minor coaxing) and either numpy (recommended) or Numeric (obsolete) installed and Matlab 6, 6.5 or 7.x under Linux, OS X® and Windows® (see OS X) on 32- or 64-bit machines.

for lazy people

>>> from mlabwrap import mlab; mlab.plot([1,2,3],'-o')

a slightly prettier example

>>> from mlabwrap import mlab; from numpy import * >>> xx = arange(-2*pi, 2*pi, 0.2) >>> mlab.surf(subtract.outer(sin(xx),cos(xx)))

for a complete description: Just run

`pydoc mlabwrap`.for people who like tutorials: see below

[This is adapted from an email I wrote someone who asked me about mlabwrap.
**Compatibility Note:** Since matlab is becoming increasingly less
`double`-centric, the default conversion rules might change in post 1.0
mlabwrap; so whilst using `mlab.plot([1,2,3])` rather than
`mlab.plot(array([1.,2.,3.]))` is fine for interactive use as in the
tutorial below, the latter is recommended for production code.]

Legend: [...] = omitted output

Let's say you want to do use Matlab® to calculate the singular value
decomposition of a matrix. So first you import the `mlab` pseudo-module and
Numeric:

>>> from mlabwrap import mlab >>> import numpy

Now you want to find out what the right function is, so you simply do:

>>> mlab.lookfor('singular value') GSVD Generalized Singular Value Decompostion. SVD Singular value decomposition. [...]

Then you look up what `svd` actually does, just as you'd look up the
docstring of a python function:

>>> help(mlab.svd) mlab_command(*args, **kwargs) SVD Singular value decomposition. [U,S,V] = SVD(X) produces a diagonal matrix S, of the same dimension as X and with nonnegative diagonal elements in [...]

Then you try it out:

>>> mlab.svd(array([[1,2], [1,3]])) array([[ 3.86432845], [ 0.25877718]])

Notice that we only got 'U' back -- that's because python hasn't got something like Matlab's multiple value return. Since Matlab functions can have completely different behavior depending on how many output parameters are requested, you have to specify explicitly if you want more than 1. So to get 'U' and also 'S' and 'V' you'd do:

>>> U, S, V = mlab.svd([[1,2],[1,3]], nout=3)

The only other possible catch is that Matlab (to a good approximation) basically represents everything as a double matrix. So there are no scalars, or 'flat' vectors. They correspond to 1x1 and 1xN matrices respectively. So, when you pass a flat vector or a scalar to a mlab-function, it is autoconverted. Also, integer values are automatically converted to double floats. Here is an example:

>>> mlab.abs(-1) array([ [ 1.]])

Strings also work as expected:

>>> mlab.upper('abcde') 'ABCDE'

However, although matrices and strings should cover most needs and can be directly converted, Matlab functions can also return structs or indeed classes and other types that cannot be converted into python equivalents. However, rather than just giving up, mlabwrap just hides this fact from the user by using proxies: E.g. to create a netlab neural net with 2 input, 3 hidden and 1 output node:

>>> net = mlab.mlp(2,3,1,'logistic')

Looking at `net` reveals that is a proxy:

>>> net <MLabObjectProxy of matlab-class: 'struct'; internal name: 'PROXY_VAL0__'; has parent: no> type: 'mlp' nin: 3 nhidden: 3 nout: 3 nwts: 24 outfn: 'linear' w1: [3x3 double] b1: [0.0873 -0.0934 0.3629] w2: [3x3 double] b2: [-0.6681 0.3572 0.8118]

When `net` or other proxy objects a passed to mlab functions, they are
automatically converted into the corresponding Matlab-objects. So to obtain
a trained network on the 'xor'-problem, one can simply do:

>>> net = mlab.mlptrain(net, [[1,1], [0,0], [1,0], [0,1]], [0,0,1,1], 1000)

And test with:

>>> mlab.mlpfwd(net2, [[1,0]]) array([ [ 1.]]) >>> mlab.mlpfwd(net2, [[1,1]]) array([ [ 7.53175454e-09]])

As previously mentioned, normally you shouldn't notice at all when you are working with proxy objects; they can even be pickled (!), although that is still somewhat experimental.

mlabwrap also offers proper error handling and exceptions! So trying to pass only one input to a net with 2 input nodes raises an Exception:

>>> mlab.mlpfwd(net2, 1) Traceback (most recent call last): [...] mlabraw.error: Error using ==> mlpfwd Dimension of inputs 1 does not match number of model inputs 2

Warning messages (and messages to stdout) are also displayed:

>>> mlab.log(0) Warning: Log of zero. array([ [ -inf]])

To get a vague impression just *how* high-level all this, consider attempting to
do something similar to the first example with pymat (upon which the
underlying mlabraw interface to Matlab® is based).

this:

>>> A, B, C = mlab.svd([[1,2],[1,3]], 0, nout=3)

becomes this:

>>> session = pymat.open() >>> pymat.put(session, "X", [[1,2], [1,3]]) >>> pymat.put(session, "cheap", 0) >>> pymat.eval(session, '[A, B, C] = svd(X, cheap)') >>> A = pymat.get(session, 'A') >>> B = pymat.get(session, 'B') >>> C = pymat.get(session, 'C')

Plus, there is virtually no error-reporting at all, if something goes wrong in
the `eval` step, you'll only notice because the subsequent `get` mysteriously
fails. And of course something more fancy like the netlab example above (which
uses proxies to represent matlab class instances in python) would be
impossible to accomplish in pymat in a similar manner.

However *should* you need low-level access, then that is equally available
(and *with* error reporting); basically just replace `pymat` with
`mlabraw` above and use `mlab._session` as session), i.e

>>> from mlabwrap import mlab >>> import mlabraw >>> mlabraw.put(mlab._session, "X", [[1,2], [1,3]]) [...]

Before you resort to this you should ask yourself if it's really a good idea;
the inherent overhead associated with Matlab's C interface appears to be quite
high, so the additional python overhead shouldn't normally matter much -- if
efficiency becomes an issue it's probably better to try to chunk together
several matlab commands in an `.m`-file in order to reduce the number of
matlab calls. If you're looking for a way to execute "raw" matlab for specific
purposes, `mlab._do` is probably a better idea. The low-level `mlabraw`
API is much more likely to change in completely backwards incompatible ways in
future versions of mlabwrap. You've been warned.

- Handling of as arrays of (array) rank 3 or more as well as non-double/complex arrays (currently everything is converted to double/complex for passing to Matlab and passing non-double/complex from Matlab is not not supported). Both should be reasonably easy to implement, but not that many people have asked for it and I haven't got around to it yet.
- Better support for cells.
- Thread-safety. If you think there's a need please let me know (on the project mailing list); at the moment you can /probably/ get away with using one seperate MlabWrap object per thread without implementing your own locking, but even that hasn't been tested.

So how does it all work?

I've got a C extension module (a heavily bug-fixed and somewhat modified version of pymat, an open-source, low-level python-matlab interface) to take care of opening Matlab sessions, sending Matlab commands as strings to a running Matlab session and and converting Numeric arrays (and sequences and strings...) to Matlab matrices and vice versa. On top of this I then built a pure python module that with various bells and whistles gives the impression of providing a Matlab "module".

This is done by a class that manages a single Matlab session (of which `mlab`
is an instance) and creates methods with docstrings on-the-fly. Thus, on the
first call of `mlab.abs(1)`, the wrapper looks whether there already is a
matching function in the cache. If not, the docstring for `abs` is looked up
in Matlab and Matlab's flimsy introspection abilities are used to determine
the number of output arguments (0 or more), then a function with the right
docstring is dynamically created and assigned to `mlab.abs`. This function
takes care of the conversion of all input parameters and the return values,
using proxies where necessary. Proxy are a bit more involved and the proxy
pickling scheme uses Matlab's `save` command to create a binary version of
the proxy's contents which is then pickled, together with the proxy object by
python itself. Hope that gives a vague idea, for more info study the source.

It looks like this particular version of matlab might be broken (I was able to
reproduced the problem with just a stripped down `engdemo.c` under 64-bit
linux). R2008b is reported to be working correctly (as are several earlier
versions).

`setup.py` will call `matlab` in an attempt to query the version and other
information relevant for installation, so it has to be in your `PATH`
*unless* you specify everything by hand in `setup.py`. Of course to be able
to use `mlabwrap` in any way `matlab` will have to be in your path anyway
(unless that is you set the environment variable `MLABRAW_CMD_STR` that
specifies how exactly Matlab® should be called).

If you see something like `mlabraw.error: Unable to start MATLAB(TM) engine`
then you may be using an incompatible C++ compiler (or version), or if you're
using unix you might not have `csh` installed under `/bin/csh`, see below.
Try if you can get the `engdemo.c` file to work that comes with your Matlab
installation -- engdemo provides detailed instructions, but in a nutshell:
copy it to a directory where you have write access and do
(assuming Matlab is installed in /opt/MatlabR14 and you're running unix,
otherwise modify as requird):

mex -f /opt/MatlabR14/bin/engopts.sh engdemo.c ./engdemo

if you get `Can't start MATLAB engine` chances are you're trying to use a
compiler version that's not in Mathworks's list of compatible compilers or
something else with your compiler/Matlab installation is broken that needs to
be resolved before you can successfully build mlabwrap. Chances are that you
or you institution pays a lot of money to the Mathworks, so they should be
happy to give you some tech support. Here's what some user who recently
(2007-02-04) got Matlab 7.04's mex support to work under Ubuntu Edgy after an
exchange with support reported back; apart from installing gcc-3.2.3, he did
the following:

The code I'd run (from within Matlab) is... > mex -setup; # then select: 2 - gcc Mex options > optsfile = [matlabroot '/bin/engopts.sh']; > mex -v -f optsfile 'engdemo.c'; > !./engdemo;

**Update** John Bender reports that under unix csh needs to be installed in
`/bin/csh` for the matlab external engine to work -- since many linux
distros don't install csh by default, you might have to do something like
`sudo apt-get install csh` (e.g. under ubuntu or other debian-based
systems). He also pointed out this helpful engdemo troubleshooting page at
the Mathworks(tm) site.

As above, first try to see if you can get engdemo.c to work, because as long as even the examples that come with Matlab® don't compile, chances of mlabwrap compiling are rather slim. On the plus-side if the problem isn't mlabwrap specific, The Mathworks® and/or Matlab®-specific support forums should be able to help.

If you get something like this on `python setup.py install`:

mlabraw.cpp:634: `engGetVariable' undeclared (first use this function)

Then you're presumably using an old version of Matlab (i.e. < 6.5);
`setup.py` ought to have detected this though (try adjusting
`MATLAB_VERSION` by hand and write me a bug report).

Josh Marshall tried it under OS X and sent me the following notes (thanks!).

Before running python, run:

export DYLD_LIBRARY_PATH=$DYLD_LIBRARY_PATH$:/Applications/MATLAB701/bin/mac/ export MLABRAW_CMD_STR=/Applications/MATLAB701/bin/matlab

[Edit: I'm not sure

`DYLD_LIBRARY_PATH`modification is still necessary.]As far as graphics commands go, the python interpreter will need to be run from within the X11 xterm to be able to display anything to the screen. ie, the command for lazy people

>>> from mlabwrap import mlab; mlab.plot([1,2,3],'-o')

won't work unless python is run from an xterm, and the matlab startup string is changed to:

export MLABRAW_CMD_STR="/Applications/MATLAB701/bin/matlab -nodesktop"

I'm thankfully not using windows myself, but I try to keep mlabwrap working under windows, for which I depend on the feedback from windows users.

Since there are several popular C++ compilers under windows, you might have to tell setup.py which one you'd like to use (unless it's VC 7).

George A. Blaha sent me a patch for Borland C++ support; search for "Borland C++" in setup.py and follow the instructions.

Dylan T Walker writes mingw32 will also work fine, but for some reason (distuils glitch?) the following invocation is required:

> setup.py build --compiler=mingw32 > setup.py install --skip-build

People sometimes try to pass a python function to a matlab function (e.g.
`mlab.fzero(lambda x: x**2-2, 0)`) which will result in an error messages
because callbacks into python are not implemented (I'm not even it would even
be feasible). Whilst there is no general workaround, in some cases you can
just create an equivalent matlab function on the fly, e.g. do something like
this: `mlab.fzero(mlab.eval('@(x) x^2-2', 0))`.

In certain (rare!) certain cases it might be necessary to directly access or
set a global variable in matlab. In these cases you can use `mlab._get('SOME_VAR')`
and `mlab._set('SOME_VAR', somevalue)`.

Private email is OK, but the preferred way is via the project mailing list

Andrew Sterian for writing pymat without which this module would never have existed.

Matthew Brett contributed numpy compatibility and nice setup.py improvements (which I adapted a bit) to further reduce the need for manual user intervention for installation.

I'm only using linux myself -- so I gratefully acknowledge the help of Windows and OS X users to get things running smoothly under these OSes as well; particularly those who provided patches to setup.py or mlabraw.cpp (Joris van Zwieten, George A. Blaha and others).

Matlab is a registered trademark of The Mathworks.
